True Planetary Gearheads

Model Number: DT090-050-0-RM090-39
Serial Number: 672187

Product Description:
- Ratio: 50:1
- Frame size: 90mm
- Precision: 8 arc-minutes
- T_peak: 167Nm
- J: 1.63kg-cm²
- Torsional Stiffness: 5Nm/arc-min

Rated Output Torque at 10,000hr
T_{rated, 1000rpm}: 88Nm
T_{rated, 2000rpm}: 84Nm
T_{rated, 3000rpm}: 82Nm
T_{rated, 4000rpm}: 81Nm

Brand
Model Number: DT090-050-0-RM090-39
Serial Number: 672187
Application
