True Planetary Gearheads

Model Number: DT115-005
Serial Number: 299923

Product Description:
- Ratio: 5:1
- Frame size: 90mm
- Precision: 8 arc-minutes
- T_peak: 284Nm
- J: 2.88kg-cm²
- Torsional Stiffness: 11.6Nm/arc-min

Rated Output Torque at 10,000hr
T_{rated, 1000rpm}: 116Nm
T_{rated, 2000rpm}: 91Nm
T_{rated, 3000rpm}: 83Nm
T_{rated, 4000rpm}: 77Nm

Brand
Model Number: DT115-005
Serial Number: 299923
Application
